| Стандарты | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6 |
| Coverage | Large homes |
| Скорость передачи данных | 802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
802.11ax (2.4GHz) : up to 574 Mbps
802.11ax (5GHz) : up to 1201 Mbps |
| Антенна | Internal dual-band antenna x 2 |
| Transmit/Receive | MIMO technology
2.4 GHz 2 x 2
5 GHz 2 x 2 |
| Память | 256 MB Flash
256 MB RAM |
| Wi-Fi Technology | OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth |
| Рабочая частота | 2.4 GHz / 5 GHz |
| Шифрование | WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise, WPA2-Enterprise, WPS support |
| Управление | UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log |
| Поддержка VPN | IPSec Pass-Through
PPTP Pass-Through
OpenVPN server
PPTP client
L2TP client
OpenVPN client |
| Тип подключения WAN | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Программы и утилиты | Router setup wizard; Firmware restoration; Device discovery; printer setup utility |
| Интерфейсы | RJ45 for 1000 BaseT for WAN/LAN x 1, RJ45 for 1000 BaseT for LAN x 1 |
| Функции | Router app
MU-MIMO
Airtime Fairness
Smart Connect
Traffic Analyzer
Traditional QoS
AiProtection Classic
Parental Control
Guest Network : 9
VPN server : PPTP Server, OpenVPN Server, IPSec server
VPN client : PPTP client, L2TP client, OpenVPN client
IPTV support
OFDMA
Bandwidth Limiter
Beamforming |
| Кнопки | WPS Button, Reset Button |
| Светодиодные индикаторы | Power x 1 |
| Питание | AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1.5 A current |
| Совместимость с ОС | Windows® 10
Windows® 8
Windows® 7
Mac OS X 10.6 or Above
iOS9.0 (Optional) or higher
Android TM |
| Размеры | 9.0 x 9.0 x 8.0 cm (WxDxH) |
| Масса | 295 g |
| Комплект поставки | Router (XD4R)
Node (XD4N)
RJ45
Adapter
QSG
Warranty Card |
| Примечание | *Router(XD4R):1x Gigabit WAN/LAN port;1x Gigabit LAN Port; Weight: 295g
*Node(XD4N):1x Gigabit LAN Port; Weight: 290g
*Content may vary in different regions. |
