Display
Diagonal Viewing Size
60.47 cm
23.8"
Panel Type
In-Plane switching Technology
Preset Display Area
527.04 mm x 296.46 mm
20.75" x 11.67"
156246.27 mm? (242.18 inches?)
Contrast Ratio
1000: 1 (typical)
Backlight Technology
LED
Brightness
250 cd/m? (typical)
Adjustabililty
Tilt (-5° to 21°)
Built in cable-management
Response Time
8ms (gray to gray)
Viewing angle
(178° vertical / 178° horizontal)
Color Support
Color Gamut (typical):
87% (CIE 1976), 72% (CIE 1931)
Color Depth:
16.7 Million colors
Color Calibration SDK SW
No
Color Calibration with X-rite colorimeter
No
Pixel Pitch
0.275 mm x 0.275 mm
Display Screen Coating
Antiglare with 3H hardness
Aspect Ratio
(16:9)
Maximum Preset Resolution
1920 x 1080 at 60Hz
Pixel Per Inch (PPI)
96
Wireless Charging Feature
N/A
G-SYNC Support
N/A
PbP / PiP
PbP (No)
PiP (No)
Daisy Chain Availability
No
Dell Display Manager Compatibility
Yes
Remote Asset Management
Yes, via Dell Command /Monitor
Audio Output
Optional Soundbar - (AC511)
Connectivity
1 x DP (ver 1.2)
1 x VGA
Built-in Devices
N/A
Security
Security lock slot (cable lock sold separately)
Anti-theft stand lock slot (to panel)
Dimensions
Height with stand
425.1 mm
16.73"
Width with stand
562.6 mm
22.15"
Depth with stand
179.9 mm
7.08"
Height without stand
333.1 mm
13.11"
Width without stand
562.6 mm
21.15"
Depth without stand
53.5mm
2.11"
Weight (panel only - for VESA mount)
3.28 kg
7.23 lb
Weight (with packaging)
5.77 kg
12.72 lb
Power
Voltage Required
100 to 240 VAC / 50 or 60 Hz ± 3Hz / 1.5 A (typical)
Power Consumption (Operational)
22W (typical) / 25W (maximum) / 54 kWh (Energy Star)
Power Consumption Stand by / Sleep
Less than 0.3W
Environmental
Temperature Range
Operating: 0° to 40°C (32° to 104°F)
Non-operating: -20° to 60° (-4° to 140° F)
Humidity Range
Operating: 10% to 80% (non-condensing)
Non-Operating:5% to 90% (non-condensing)
Altitude
Operating: 5,000 m (16,404 ft) max
Non-Operating: 12,192 m (40,000 ft) max
Regulatory
Compliant Standards
ENERGY STAR
EPEAT gold
TCO Certified Displays
RoHS Complaint
Product Safety, EMC and Environmental Datasheets
Dell Regulatory Compliance Home Page
Dell and the Environment
What's Included
Monitor with stand
Power cable
1 x DP Cable
1 x VGA Cable (Europe, Middle East, Africa and Japan only)
Drivers and documentation media
Quick setup guide
Safety Information
36 Месяц
Китай
| Основные |
|---|
| Тип устройства | монитор |
| Диагональ экрана | 23.8 " 60.47 см |
| Покрытие экрана | Антибликовое |
| Поддержка сторон | 16:9 |
| Тип матрицы | IPS |
| Технические характеристики |
|---|
| Рекомендуемое разрешение | 1920x1080 (Full HD) |
| Время реакции | 8 мс |
| LED подсветка |  |
| Контрастность (статическая) | 1000:1 |
| Яркость | 250 кд/м2 |
| Угол обзора по вертикали | 178 ° |
| Угол обзора по горизонтали | 178 ° |
| Глубина цвета | 16.7 млн. цветов |
| Разъемы |
|---|
| Входы | VGA
DP |
| Дополнительно |
|---|
| Потребляемая мощность | 22 Вт 25 Вт - максимальное |
| Стандарт безопасности | TCO
Energy Star
EPEAT Gold
RoHS |
| Цвет | черный |
| Габариты (ШхВхТ) | 562.6x333.1x53.5 мм |
| Вес | 3.28 кг 5.77 кг с упаковкой |
| Наклон | 21 ° до –5° |
