Display
Diagonally Viewable Size:
86.72 cm (34.14 Inches)
Preset Display Area(H X V):
799.80 mm x 334.80 mm
31.49" x 13.18"
267773.04 mm? (415.01 inches? )
Aspect Ratio:
21:9
Backlight Technology:
White LED edge light system
Display Screen Coating:
Anti-glare with 3H hardness
Panel Type :
In-Plane Switching Technology
Maximum Preset Resolution:
3440 x 1440 at 60 Hz
Border Width (Edge of Monitor active area)
10.55 mm (Top)
10.05 mm (Left/Right)
Curve radius:
1900R
Viewing Angle:
178° vertical / 178° horizontal
Contrast Ratio:
1000 to 1 (typical)
5M to 1 (typical Dynamic Contrast On)
Pixel Pitch:
0.233 mm x 0.233 mm
Pixel Per Inch (PPI):
109
Brightness:
300 cd/m? (typical)
Response Time:
5 ms (typical) for FAST mode
8 ms (typical) for NORMAL mode
PbP/PiP:
PbP (Yes)
PiP (Yes)
Daisy Chain Availability:
Yes
Dell Display Manager Compatibility:
Yes with Easy Arrange
Remote Asset Management:
Yes, via Dell Command /Monitor
Color Support:
Color Gamut (typical):99% sRGB (Delta E < 3)
Color Depth: 1.07 Billion colors
Audio Output:
2 x 9W speakers, 1 x Analog 2.0 audio line out (3.5mm jack)
Stand
Height adjustable Stand (up to 115mm)
Tilt (-5°/21°)
Swivel (-30° to 30°)
Built in cable-management
Flat Panel Mount Interface:
VESA (100 mm)
Connectivity
1 DP 1.2 (HDCP 1.4)
1 mDP 1.2 (HDCP 1.4)
1 DP 1.2 (out) with MST (HDCP 1.4)
2 HDMI 2.0 (HDCP 1.4)
4 USB 3.0 downstream port (2 x BC1.2 charging capabilities at 2A (max))
2 USB 3.0 upstream port
Built-in Devices
USB3.0 Hi-Speed Hub (2 USB upstream port and 4 USB downstream, with 2 x BC1.2 charging capability at 2A (max))
Security
Security lock slot (cable lock sold separately)
Dimensions
Dimensions with stand (H x W x D):
Height:
Compressed : 417.0 mm (16.42 inches)
Extended : 532.0 mm (20.94 inches)
Width: 813.6 mm (32.03 inches)
Depth: 226.4 mm (8.91 inches)
Dimensions without stand (H x W x D):
Height: 363.7 mm (14.32 inches)
Width: 813.6 mm (32.03 inches)
Depth: 58.4 mm (2.30 inches)
Weight:
With packaging: 15.4 kg (33.94 lb)
Panel only–for VESA mount: 7.7 kg (16.97 lb)
Power
Voltage Required:
100 VAC to 240 VAC / 50 Hz or 60 Hz + 3 Hz / 1.5 A (typical)
Power Consumption (Operational):
50W (typical) / 130W (maximum)
Power Consumption Stand by / Sleep:
Less than 0.5W
Environmental
Temperature Range
Operating: 0°C to 40°C (32°F to 104°F)
Non-operating: -20°C to 60°C (-4°F to 140° F)
Humidity Range
Operating: 10% to 80% (non-condensing)
Non-Operating:5% to 90% (non-condensing)
Altitude
Operating: 5,000 m (16,404 ft) max
Non-Operating: 12,191 m (40,000 ft) max
Regulatory
RoHS Compliant
BFR/PVC Free monitor(excluding external cables)
Product Safety, EMC and Environmental Datasheets
Dell Regulatory Compliance Home Page
Dell and the Environment
What's in the box
Monitor with stand
Power cable
HDMI Cable
DP to mDP Cable
USB 3.0 upstream cable
Drivers and documentation media
Quick setup guide
Safety, Environmental, and Regulatory Information
Factory Calibration Report
36 Месяц
Китай
Основные |
---|
Тип устройства | монитор |
Назначение | для игр |
Диагональ экрана | 34 " |
Покрытие экрана | Антибликовое |
Поддержка сторон | 21:9 |
Тип матрицы | IPS |
Изогнутый экран | да |
Технические характеристики |
---|
Рекомендуемое разрешение | 3440х1440 |
Время реакции | 8 мс /в ускоренном режиме - 5 мс |
LED подсветка | есть |
Контрастность (статическая) | 1000:1 |
Контрастность (динамическая) | 5000000:1 |
Яркость | 300 кд/м2 |
Угол обзора по вертикали | 178 ° |
Угол обзора по горизонтали | 178 ° |
Размер пикселя | 0.233 мм |
Частота обновления | 60 Гц |
Глубина цвета | 1.074 млрд. цветов |
Разъемы |
---|
Входы | Display Port mini Display Port HDMI USB 3.0 /4 принимающих порта + 2 передающих порта |
Количество HDMI | 2 шт |
Выходы | Аудиовыход (line-out) /для наушников 3.5 мм |
Функциональные возможности |
---|
Встроенные динамики | есть |
Мощность звука | 2х9 Вт |
Дополнительно |
---|
Настенное крепление VESA | 100x100 |
Потребляемая мощность | 50 Вт |
Гнездо для замка Kensington | тросовый замок приобретается отдельно |
Цвет | серебристый с черным |
Габариты (ШхВхТ) | 813.6 х 58.4 х 363.7 мм без подставки/813.6 х 226.4 х 532 - с подставкой |
Вес | 7.7 кг /с упаковкой: 15.4 кг |
Наклон | -5 ° +21° |
